Technical Specifications:
| Speed range(rpm) |
0-21000rpm adjustable |
Speed accuracy |
±10rpm |
| Max Capacity(ml) |
4*100ml |
RCF range (xg) |
0-31061xg adjustable |
| Display |
LCD |
Time range |
0-99minutes 59s adjustable |
| Noise(dBA) |
≦58dB(A) |
Acceleration /Deceleration rates |
1-- 10 |
| Dimension(mm) |
470x345x295mm |
Motor |
Frequency Converter motor |
| Net weight(without rotor) |
30KGS |
Power supply |
AC220V,50HZ,10A,600W |
Matched Rotors(Customized rotors are available)
| No. |
Item |
Capacity |
Max.speed |
Max.RCF |
Note |
| NO.1 |
Angle rotor |
12×1.5/2.2ml |
21000r/min |
31061xg |
PP/PC tube |
| Adapter |
12×0.5/0.2ml |
PP/PC tube |
| NO.2 |
Angle rotor |
24×1.5/2.2ml |
16000r/min |
22896xg |
PP/PC tube |
| Adapter |
24×0.5/0.2ml |
PP/PC tube |
| NO.3 |
Angle rotor |
48×1.5/2.2ml |
14000r/min |
20378xg |
PP/PC tube |
| Adapter |
48×0.5/0.2ml |
PP/PC tube |
| NO.4 |
Angle rotor |
12×5ml |
16000r/min |
18317xg |
PP/PC tube |
| Adapter |
12×1.5ml |
PP/PC tube |
| Adapter |
12×0.5/0.2ml |
PP/PC tube |
| NO.5 |
Angle rotor |
12×8×0.2ml |
14000r/min |
23120xg |
PCR 8-tube strips |
| NO.6 |
Angle rotor |
12×10ml |
15000r/min |
23120xg |
PP/PC tube |
| Adapter |
12×5ml |
PP/PC tube |
| Adapter |
12×1.5ml |
PP/PC tube |
| Adapter |
12×0.5/0.2ml |
PP/PC tube |
| NO.7 |
Angle rotor |
6×50ml |
13000r/min
|
17005xg
|
PP/PC tube |
| Adapter |
6×15ml |
PP/PC tube |
| Adapter |
6×3×1.5ml |
PP/PC tube |
| NO.8 |
Angle rotor |
10×15ml |
13000r/min |
20595xg
|
PP/PC tube |
| Adaptor |
10×5ml |
PP/PC tube |
| Adapter |
10×1.5/0.5/0.2ml |
PP/PC tube |
| NO.9 |
Angle rotor |
4×100ml |
11000r/min |
13280xg |
PP/PC tube |
| Adapter |
4×50ml |
PP/PC tube |
| Adapter |
4×15/10ml |
PP/PC tube |
| Adapter |
4×5/1.5ml |
PP/PC tube |
Feature
· Compact and space-saving centrifuge
· Speed range up to 21000 r/min
· Max.RCF: 31061xg
· Max.capacity: 4*100ml fixed angle rotor
· Research Use 20000 rpm Centrifuge Machine T21-M use A.C. Frequency conversion motor direct drive, high precision, low noise, long service life
· Microcomputer control, color break code LED screen display, program can be programmed and stored, speed, centrifugal force, time can be displayed at the same time.
· 3 levels damping for anti vibration. Programmable and storable, stores up to 30 programs and provides direct user access with one keystroke save. The stored parameter: combination remains in the memory even after the centrifugation has been switched off.
· Research Use 20000 rpm Centrifuge Machine T21-M Provides the 10 acceleration rates and 10 braking ramp, to effectively avoid secondary sedimentation, with better centrifugation effect.
· Automatic lid-locking and holding during rotor run
· Automatic rotor identification system, coded rotor identification prevents the rotor from over speeding.
· Easily exchangeable rotors, special rotor connector which makes it easy to load and unload rotor.
· Automatic troubleshooting with indication of error code and alarm on the screen.
· Research Use 20000 rpm Centrifuge Machine T21-M features “Mute”patent technology. Noise level lower than 58 decibel at the highest rotational speed (patent no. ZL201721835868.9).
· Speed up to 21000rpm depends on rotor type
· With over-speed, over-temperature, electronic safety door lock and other multi-level protection functions to ensure the safety of man and machine.
