Product Details:
|
Type: | High Speed Mini Centrifuge | Max Rpm: | 16500rpm |
---|---|---|---|
Max Capacity: | 12x 15ml | Acceleration/Deceleration: | 10 Levels |
Noise Level: | <55dB(A) | Rotor Material: | Aluminum Alloy |
Max RCF: | 19480 Xg | Power Supply: | AC 220V/110V, 50Hz/60Hz |
Highlight: | 16500 rpm High Speed Mini Centrifuge,Small Size High Speed Mini Centrifuge |
The Labtech HK-16C micro centrifuge offers a wide selection of rotors tailored to different requirements, accommodating PCR strips, filter tubes, as well as 2ml and 5ml micro-liter tubes. Its outstanding performance and versatile rotor choices make it ideal for various applications, including microbiological research, protein biochemistry, and clinical chemistry. Utilizing micro tubes ranging from 1.5ml to 5ml, this centrifuge serves diverse purposes like sample pelleting, sedimentation, preparation, and purification.
Technical Specifications:
Max. RPM / Fixed angle | 16,500rpm/ 19,480 x g | Speed accuracy | ±10r/min |
Max.Capacity,Fixed Angle | 12 x 5ml | Noise level (dB) | ≦55dB(A) |
Safety lid lock | Yes | ACC/DEC | 10/10 steps |
Max. acceleration time [s] | 15 seconds | Max. braking time [s] | 15 seconds |
Display | LCD | Program memory | 10 |
Automatic rotor identification | Yes | Lid drop protection | Yes |
Motorized lid open & close | Yes | Imbalance cut-off | Yes |
Parameters on display window | RPM (RCF), Time, ACC, DEC | Power requirement | 370 W |
Time control |
1-99minutes 59s adjustable |
Power supply |
AC220V,50HZ,10A; 110V optional |
Dimension (W x D x H, mm) | 340*260*220mm | Weight without rotor (kg) | 15 kg |
Diverse Choice of Rotors:
No. | Rotor | Max.Capacity | Max. speed | Max. RCF | Note |
NO.1
|
Angle rotor | 12×1.5/2.2ml | 16500r/min | 19175xg | EP/PP tube |
Adapter | 12×0.5/0.2ml | EP/PP tube | |||
NO.2
|
Angle rotor | 12×5ml | 16500r/min | 19480xg | EP/PP tube |
Adapter | 12×1.5ml | EP/PP tube | |||
NO.3
|
Angle rotor | 8×8×0.2ml | 13500r/min | 16480xg | PCR 8 strip tubes |
NO.4
|
Angle rotor | 24×1.5-2.2ml | 14000r/min | 17530xg | EP/PP tube |
Adapter | 24×0.5/0.2ml | EP/PP tube | |||
|
Features of High Speed Mini Centrifuge:
· Benchtop Microcentrifuges High Speed Clinical Centrifuge HK-16C use Microprocessor control with frequency conversion A.C. motor drive.
· Large LED display clearly shows the operation status, parameters such as speed, timer, RCF, rotor, program (memory), acceleration and deceleration information and error code information.
· Benchtop Microcentrifuges High Speed Clinical Centrifuge HK-16C Provides 10 acceleration rates and 10 braking ramps to effectively avoid secondary sedimentation and better centrifugation results. Fast acceleration rate reaches 165,000rpm in 15 seconds, and so does the braking ramp.
· Benchtop Microcentrifuges High Speed Clinical Centrifuge HK-16C offers Automatic cap locking and fixing during rotor operation
· Rotor can be easily replaced
· Benchtop Microcentrifuges High Speed Clinical Centrifuge HK-16C's Noise level below 55 dBA at maximum rotational speed.
· Automatic troubleshooting with error codes and alarms displayed on screen.
· Safe electrical lid interlock, door cannot be opened while rotor is running, machine will not run with lid open and error codes appear.
